Turbine Agitator

Get a Price/Quote

Product Details:

Voltage 220V / 380V / 415V
Accuracy High Mixing Uniformity
Power Rating Totally Enclosed Fan Cooled (TEFC) Motor as per rating
Noise Level < 75 dB
Connectivity Options Direct coupled / Belt drive
Features Robust construction, corrosion resistance, energy efficient
Motor Power Customizable as per mixing requirement
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Turbine Agitator Price And Quantity

Minimum Order Quantity 1 Unit

Turbine Agitator Product Specifications

Voltage 220V / 380V / 415V
Usage & Applications Chemical, Pharmaceutical, Food Processing, Water Treatment
Weight (kg) Varies with size and model; typically 40 - 200 kg
Pressure Atmospheric or as specified
Power Source Electric Motor Driven
Features Robust construction, corrosion resistance, energy efficient
Dimension (L*W*H) As per customer requirement or standard model sizes
Connectivity Options Direct coupled / Belt drive
Noise Level < 75 dB
Accuracy High Mixing Uniformity
Power Rating Totally Enclosed Fan Cooled (TEFC) Motor as per rating
Lubricating System Grease / Oil lubricated bearings
Technology Mechanical Agitation
Production Capacity Up to 30 KL batch size
Frame Type Heavy Duty Frame
Cooling System Air Cooled Motor
Machine Type Vertical / Horizontal Mount
Model No As per manufacturer catalogue
Power 0.5 HP to 20 HP (customizable)
Product Type Turbine Agitator
Operating Temperature Up to 120C
Motor Power Customizable as per mixing requirement
Color Silver / Grey / Blue
Frequency 50/60 Hz
Surface Treatment Painted / Powder coated / Polished
Control System Manual / PLC Control
Drive Direct or Gearbox coupled
Operating Type Manual/Automatic

Suitable for Viscosity Low, Medium, High viscosity fluids
Impeller Type Turbine multi-blade or paddle
Agitation Level Mild to vigorous
Seal Type Mechanical seal / Gland packing
Shaft Length Customizable as per tank depth
Mounting Options Top, Side or Bottom entry
Mixing Time Depends on tank size & viscosity
Material of Construction Stainless Steel (SS304 / SS316) or Carbon Steel
Shaft Diameter According to application
Service On-site installation and maintenance available

Turbine Agitator Trade Information

Payment Terms Cash in Advance (CID)
Supply Ability 100 Unit Per Month
Delivery Time 10 Days
Main Domestic Market All India

Product Description

Perfect for mixing low to medium viscosity fluids, this agitator uses multiple flat or curved blades to generate high shear and axial flow, making it ideal for emulsification, dispersion, and gas-liquid mixing.

Robust & Versatile Construction

Crafted using stainless steel (SS304/SS316) or carbon steel, the Turbine Agitator stands up to harsh process conditions. Its impeller design, selection of mechanical seals or gland packing, and heavy-duty frame ensure longevity and reliability for demanding mixing applications.

Custom-Built for Every Application

Available with top, side, or bottom entry, as well as vertical or horizontal mounting, this agitator's shaft length and diameter are tailored to individual tank dimensions and mixing requirements. Options for direct or gearbox-coupled drive, plus PLC or manual control, maximize flexibility.

Superior Performance & Efficiency

The agitator is powered by a TEFC motor and designed for high mixing uniformity, accommodating viscosities ranging from low to high. Energy-efficient, air-cooled motors and customizable surface finishes provide consistent, quiet operation-even in large batch sizes.

FAQ's of Turbine Agitator:

Q: How is the Turbine Agitator installed in different tank configurations?

A: The Turbine Agitator can be mounted on the top, side, or bottom of tanks, with vertical or horizontal layouts. Our team provides on-site installation and guarantees the shaft length, diameter, and mounting style are suited to your tank's dimensions and process needs.

Q: What types of fluids and viscosities can this agitator handle?

A: It is suitable for mixing low, medium, and high viscosity fluids. Whether you are blending chemicals, pharmaceuticals, food ingredients, or water treatment additives, the agitator's customizable impeller type and agitation intensity ensure effective, uniform mixing.

Q: When should I choose a mechanical seal versus gland packing?

A: Mechanical seals provide superior leakage prevention and are ideal for hazardous or corrosive applications. Gland packing offers a cost-effective option for less critical environments. Selection depends on your specific process, safety requirements, and product characteristics.

Q: What is the process for customizing the agitator's shaft and impeller?

A: Shaft length, diameter, and impeller size are all tailored based on your tank's depth, product viscosity, and desired agitation level. Our engineering team collaborates with you to ensure the design fits your technical and operational requirements precisely.

Q: Where can the Turbine Agitator be used across industries?

A: This agitator is widely used in chemical, pharmaceutical, food processing, and water treatment plants throughout India. Its robust construction and adaptable design make it a preferred solution for diverse industrial blending and mixing processes.

Q: What are the benefits of using this Turbine Agitator for batch production?

A: It delivers high mixing uniformity, energy efficiency, and low noise output (<75 dB). With a customizable motor power (0.5-20 HP) and large batch capacity (up to 30 KL), it ensures consistent product quality, reduced batch times, and adaptable integration for various production scales.
